your Professional Steel Silo and grain silo Manufacturer, Supplier
Guangcai Steel Silo focus on grain storage, feed storage, and industrial storage solutions, and specialize in the design, development, processing, and manufacturing of prefabricated steel silo components.
Guangcai Silo has more than 14 years of experience in the silo storsge, providing professional one-stop silo storage solutions and EPC services.
Want to learn more about our steel silo and grain silo project cases?
Want to get silo capacity technical parameters and professional design solutions?
Want to upgrade your grain storage system?
We always have a product that can meet your project budget and technical requirements. Feel free to contact us at any time through the email gcsilo@silo-watertank.com.
Our professional team will provide you with detailed answers and customized design services, and look forward to exploring more possibilities of grain storage with you!
-
![Insulated Steel Silos]()
Insulated Steel SilosApplication: Grain industry: Low-temperature storage of corn, wheat, rice and other grains to inhibit pests and respiratory loss.. Silo Material: 275 - 600g/m² Galvanized & Corrugated Steel.read more -
![Large Scale Grouped Steel Silos]()
Large Scale Grouped Steel SilosApplication: Large Scale Storage Facility. Silo Material: 275 - 600g/m² Galvanized & Corrugated Steel. Silo Capacity: 1500T - 3000T. Bottom Type: Flat Bottom. Diameter: 12.8m - 16.5m. Rings:read more -
![Wheat & Corn Short Term Storage Steel Silos]()
Wheat & Corn Short Term Storage Steel SilosApplication: Short Term Storage for Wheat & Corn. Silo Material: 275 - 600g/m² Galvanized & Corrugated Steel. Silo Capacity: 1000T - 1500T. Bottom Type: Hopper Bottom. Diameter: 10.0m -read more -
![Cottonseed Hopper Steel Silos]()
Cottonseed Hopper Steel SilosApplication: Used to Store Cottonseed. Silo Material: 275 - 600g/m² Galvanized & Corrugated Steel. Silo Capacity: 100T - 150T. Bottom Type: Hopper Bottom. Diameter: 9.1m - 10.0m. Rings: 8 -read more -
![Paddy Insulated Hopper Steel Silos]()
Paddy Insulated Hopper Steel SilosApplication: Insulated Paddy Storage. Silo Material: 275 - 600g/m² Galvanized & Corrugated Steel. Silo Capacity: 2500T-3000T. Bottom Type: Hopper Bottom. Diameter: 16.5m-18.3m. Rings: 15-17.read more -
![Wet Grain Hopper Steel Silos]()
Wet Grain Hopper Steel SilosApplication: Used Before Grain Drying to Store Wet Grain. Silo Material: 275 - 600g/m² Galvanized & Corrugated Steel. Silo Capacity: 1000T-1200T. Bottom Type: Hopper Bottom. Diameter:read more -
![Dried Corn Flat Bottom Silos]()
Dried Corn Flat Bottom SilosCorn Storage Silos: Build Stable, Safe & Efficient Steel Silos for Corn Storage- Stable Structure, Excellent Sealing Performance, Good Ventilation, Environmentally Friendly & Energy-Saving, andread more -
![Dust Aspiration & Collection Systems]()
Dust Aspiration & Collection SystemsUsed for pre-cleaning of raw materials to remove large impurities, ensuring the stable operation of subsequent equipment.Low energy consumption, compact structure, small space occupation, easyread more -
![Insulated Steel Silo]()
Insulated Steel SiloGuangcai Insulated Steel SiloLight weight, low thermal conductivity, good elasticity, non-combustible and high chemical stability.read more
Steel Silo | Grain Silo Advantages
Strong Sealing
GC silo uses special bending equipment to ensure the quality of the parts during processing, resulting in a particularly well-sealed silo. Therefore, using this silo for grain storage better meets the process requirements for pesticides and fumigation.
Easy to Operate
The silo has a high degree of automation, advanced loading and unloading equipment, and is easy to operate and manage.
Built-in Temperature Measuring Device
The temperature measuring device is installed in the silo. When the temperature of the grain changes, a mobile air supply unit will be activated for safe storage. This makes the silo one of the safest, most effective, and efficient ways of storing grain.
Highly Respectful of Customer Requirements
We offer a wide range of silos designed to eliminate the risk of pests and chemical residues. Regardless of size, you receive a robust and innovative product.
Detailed Specifications
|
Product Category: |
Prefabricated Steel Silo and Grain Silo |
|
Material: |
Galvanized, aluminum-zinc coated, zinc-aluminum-magnesium coated |
|
Single Silo Capacity: |
5-16000 tons |
|
Diameter: |
1.8-32meters |
|
Structure Type: |
Assembled |
|
Applications: |
Widely used in grain, building materials, ports, environmental protection, and other industrial fields |
Features
Choose the best Prefabricated Steel Silo
Easy Component Replacement, Long Life
Prefabricated steel silos utilize high-quality hot-dip galvanized steel and standard system components, allowing for easy component replacement, extending their overall service life to 15-20 years.
Easy Assembly and Disassembly, Low Cost
Quick installation and low investment cost make them particularly suitable for operators operating leased sites, facilitating relocation and relocation.
Intelligent Early Warning, Safe and Reliable
During normal operation, if grain temperature rises to a critical point due to excessive moisture, the temperature measurement system will promptly issue an alarm, indicating the risk to specific areas and requiring ventilation and cooling (optional) to ensure safe storage.
Safety & Widely Applicable
The steel frame structure is stable and safe, making it widely applicable to various industries, including grain and oil, chemicals, brewing, pharmaceuticals, food, cement, and coal, meeting the storage needs of diverse sectors.
Steel Silo/Grain Silo Structure
1.The top feed inlet has been enlarged for easier filling of feed.
2.The movable silo cover is made of 275g/sqm hot-dip galvanized sheet, which is stretched in one process.
3.The specially designed automatic elastic torsion spring control structure and limit plate enable workers to open and close the cover freely from the ground, ensuring safety and convenience.
4.All cover fittings are made of 304 stainless steel, offering high strength, no fractures, and no rust.
The roof sheet has an air duct that balances the air pressure inside and outside the silo, discharges gases and heat, ensures smooth feeding, and keeps the silo interior clean.
Transparent observation windows are provided on both the silo ring and the silo hopper.
The windows are made from plastic injection molding, offering strong pressure resistance and good light transmittance, making it easy to check the storage status.
The mounting ladder is molded from a single piece of hot-dip galvanized steel plate with an anti-skid design, ensuring firmness, non-slip stability, and easy installation.
It is also equipped with a security cage, which is safe and reliable, providing convenience for observing the feed level and maintaining the silo.
The hopper sheets are fixed with 8.8-grade high-strength hot-dip galvanized bolts, and the exposed bolt parts are equipped with specially designed rubber nuts, which are aesthetically pleasing and rust-resistant.
Application Scope
It can be applied in feed mills, flour mills, poultry farms, wine mills, national grain depots, grain trading companies, food processing plants, etc.
Installation Instructions
If the client wants to install 10-ton to 1,500-ton steel hopper-bottom grain silos by themselves, we can offer detailed instructions and provide our quickest response to address any questions during the process.
We can also send our engineer to supervise the installation process. The client can find local workers for the installation, and our engineer will assist them throughout the process.
If the client prefers, we can send our installation team to handle the entire installation.
High-Quality Materials for Maximum Durability
Our silos are constructed using corrugated steel sheets made from pre-galvanized steel coils, supplied exclusively by approved steel manufacturers under our strict quality control system.
Material Grade: S450GD + Z600 Zinc Coating or Magnelis ZM310 or ZM430, compliant with EN-10346 standards.
Corrugation Design: Waves measuring 106 mm in length and 13 mm in depth, providing enhanced structural strength.
The wall sheet thickness varies between 0.8 mm and 3.5 mm. For added strength, we use combinations of different thicknesses based on calculation requirements to meet structural demands.
Customization Options
Not only do carbon steel grain silos offer the ability to better customize your storage solutions, but accessories such as industrial stairs and platforms are easier and cheaper to install. Silos can also be customized to have a smaller diameter without negatively impacting the full storage capacity of the unit. While steel can be easily bent, concrete is inflexible.
Our Process
CONTACT US
Start the conversation with our team today to learn more about our products, offerings, and more.
DISCUSS YOUR NEEDS
Let us know exactly what you need. We will help you find the right solution for you.
PLACE YOUR ORDER
We make ordering your custom products simple. Place your order with us and receive them quickly!
Certificate
FAQ
1. Q: How can I place an order?
A: You can contact and inform us the detail demand information, We will give you a detail quotation list. For designing or further discussion, it is better to contact us through Skype, Trademanager, Wechat, Whatsapp, or QQ. In case of any delays
2. Q: Are you a factory or Trading company?
A: we are factory, and we are guarantee that our price is first-hand with high quality
3. Q: What about your payment?
A: 30% deposit; 70% balance before shipping the cargoes, we also can accept the L/C
4. Q: what is the detail service from your company?
A: Customized designs and produces, we will supply the detail Installation Instructions with CAD/Sketch Drawing
